House Surge Protective Device, Whole Home Surge Protector, SPD Arrester 2P 4P AC 220V 230V 275V 35mm Din Rail 40kA(2P)

Gas Tube ArrestorsEAP Series Surge Protection Device was designed and manufactured, complyingstandard GB/T18802.1/EN61643-11 ,Rated voltage 275V~,320V~,385V~Maximum discharge current 40kA,High Energy Varistor, high effective for lightningprotection.EAP series surge protective devices can be widely used in various fields, including homes, distribution boxes, switchgear, fire protection, photovoltaic systems, communications, data centers, gas stations, factories, communities, elevators, control cabinets, industrial applications, renewable energy, construction, and rail .FeaturePluggable module, easy for installation and maintenanceHigh Energy Varistor, Response Time Less Than 25 NanosecondCOMMON DATA:Operating Temperature Range(Ta):-40' to +158'F[-40' to +80C]Permissible Operating Humidity(RH):5%...95%Atmospheric pressure and altitude:80k Pa...106k Pa/-500m...2000mTerminal Screw (Mmax):39.9 lbf-in [2.0~2.5-Nm]Conductor Cross Section(max):2 AWG (Solid, Stranded) / 4 AWG (Flexible)35mm' (Solid, Stranded)/25mm*(Flexible)Mounting:35mm DIN Rail, EN 60715Degree of Protection:IP20(built-in)Housing Material:Thermoplastic: Extinguishing Degree UL 94 V-0Operating State / Fault iIndication:Green: ok / Red: failureThermal Protection:yes==========High-concerned chemical : NoneType : Surge Protective DeviceType : Circuit breakerIs Smart Device : No

• Gas Tube Arrestors
• Surge Arrester 220v|House Surge Protector 220v|High Energy Varistor:Equipped with a High Energy Varistor, the surge protector offers quick response times of less than 25 nanoseconds.
• 40kA Maximum Discharge Current:With a maximum discharge current of 40kA, the device provides robust protection against strikes.
• Wide Voltage Compatibility:Designed for versatility, the surge protector supports a range of voltages from 220V to 385V, ensuring compatibility with various systems.
• Easy Installation:Featuring a pluggable module, the surge protector is simple to install and maintain, reducing downtime.
• Extensive Application:Ideal for diverse settings, from homes to industrial applications, this surge protector is a reliable choice for various environments.
